G8072 Heavy Duty Push / Pull Roller Bolt Bathroom Mortice Lock
Description
Heavy duty Push/Pull roller bolt bathroom mortice lock for use on internal wooden hinged doors. CE Marked door lock Fire rated to BS EN 1634-1:2000 & Performance rated to BS EN 12209. Roller bolt operated by push or pull from either side Deadbolt operated by turn from either side. Supplied with striker plate and fixing screws. Finishes stainless steel (SS) or satin brass (SB). Other finishes available.
Notes
Operation
Roller bolt operated by push or pull from either side Deadbolt operated by turn from either side
Case
Pierced to accept 38mm centre horizontally opposed bolt through fixing furniture
Striker Plate
Type D
Latchbolt
Brass, adjustable roller bolt to suit either hand Heavy sprung as standard. Light springing available on request
Deadbolt
Brass, Throw 14mm
Follower
Brass, to suit 5mm square spindle
Rebate Units To Suit
PP/G3051-13mm PP/G3052-19mm PP/G3053-25mm
Box
DUSTBOX1 - Sold Separately
Additional information
| Lock Case | 63mm, 76mm, 101mm |
|---|---|
| Backset | 45mm, 57mm, 82mm |
