Operation

Deadbolt operated by key from either side using a double cylinder or by key outside and thumb turn inside using a single cylinder with turn

Case

Pierced to accept 20mm and 38mm centre bolt through escutcheons

Striker Plate

Type C

Deadbolt

Brass, with two hardened steel rollers. Throw 14mm

Cylinder

Not supplied. May be used with the following cylinders: a) Key either side such as Guardian G9001 b) Turn inside and key outside such as Guardian G9002

Springing

Not supplied. May be used with the following cylinders: a) Key either side such as Guardian G9001 b) Turn inside and key outside such as Guardian G9002

Rebate Units To Suit

DL/G3051-13mm DL/G3052-19mm DL/G3053-25mm

Box

for Type 'C' Strike, DUSTBOX2 - Sold Separately
