G8055 Mortice Hookbolt for Sliding Doors
Description
Mortice hookbolt for use on wooden sliding doors. CE Marked door lock Fire rated to BS EN 1634-1:2000 & Performance rated to BS EN 12209. Bolt operated by turn from either side. Supplied with striker plate and fixing screws. Finishes stainless steel (SS) or satin brass (SB). Other finishes available.
Notes
Operation
Bolt operated by turn from either side
Case
Pierced to accept 38mm centre horizontally opposed bolt through fixing furniture
Striker Plate
Type Y
Deadbolt
Brass, hook with anti-lift bar. Throw 19mm
Follower
Die cast, nickel plated, to suit 5mm square spindle
Rebate Units To Suit
Not available
Additional information
| Lock Case | 76mm |
|---|---|
| Backset | 57mm |
